| Projector type |
1-Chip DLP™ projectors |
| DLP™ Chip | Panel Size |
0.8 in diagonal (16:10 aspect ratio) |
| DLP™ Chip | Display Method |
DLP™ chip x 1, DLP™ projection system |
| DLP™ chip | Number of Pixels |
2,304,000 (1920 x 1200 pixels) |
| Light Source |
Laser Diode |
| Light Output*1 *2 |
15,000 lm / 15,500 lm (Center)*3 |
| Screen size [diagonal] |
70–1000 inches (with ET-C1S600) |
| Resolution |
4K (3840 x 2400 pixels) (Quad Pixel Drive: ON) |
| Contrast Ratio*1 |
25,000:1 (Full On/Full Off, Dynamic Contrast [3]) |
| Time until light output declines to 50 %*4 |
20,000 hours (NORMAL/QUIET), 24,000 hours (ECO) |
| Center-to-corner zone ratio*1 |
90% |
| Lens |
PT-REQ15 : Powered zoom (throw ratio 1.36–2.10:1 for supplied lens), powered focus; PT-REQ15L : Optional powered zoom/focus lenses |
| Lens shift | Vertical(From the origin point of the lens mounter) |
±60 % (with ET-C1W400/W500/S600/T700), ±50 % (with ET-C1W300/U100) |
| Lens shift | Horizontal(From the origin point of the lens mounter) |
±29 % (with ET-C1W400/W500/S600/T700), ±23 % (with ET-C1W300/U100) |
| Keystone Correction Range |
Vertical: ±40 ° (±5 ° with ET-C1U100; ±10 ° with ET-C1W300; ±16 ° with ET-C1W400; ±22 ° with ET-C1W500), Horizontal: ±40 ° (±3 ° with ET-C1U100; ±5 ° with ET-C1W300; ±10 ° with ET-C1W400; ±15 ° with ET-C1W500) |
| Installation |
Ceiling/floor, front/rear, free 360-degree installation |
| Terminals | HDMI™ 1/2 IN |
HDMI™ x 2 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input) |
| Terminals | DisplayPort™ |
DisplayPort™ x 1 (Deep Color, compatible with HDCP 2.3, 4K/60p signal input) |
| Terminals | Multi Sync In |
BNC x 1 |
| Terminals | Multi Sync Out |
BNC x 1 |
| Terminals | Serial In |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals | Serial Out |
D-sub 9-pin (male) x 1 for link control (RS-232C compliant) |
| Terminals | REMOTE 1 IN |
M3 stereo mini-jack x 1 for wired remote control |
| Terminals | REMOTE 1 OUT |
M3 stereo mini-jack x 1 for link control (for wired remote control) |
| Terminals | Remote 2 In |
D-sub 9-pin (female) x 1 for external control (parallel) |
| Terminals | LAN |
RJ-45 x 1 for network connection, PJLink™ (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
| Terminals | USB |
USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module/USB memory |
| Terminals | DC Out |
USB Type A x 1 (for power supply, DC 5 V, 2 A) |
| Terminals | Expansion Slot |
Open slot for for function boards, Intel® SDM compatible |
| Protocol versions |
IPv4, IPv6*5 |
| Power Supply |
AC 100–240 V, 50/60 Hz |
| Power Consumption*6 | On-mode power consumption (Operating mode) Nomal |
985 W (AC 100–120 V), 940 W (AC 200–240 V) |
| Power Consumption*6 | On-mode power consumption (Operating mode) ECO |
765 W (AC 100–120 V), 735 W (AC 200–240 V) |
| Power Consumption*6 | On-mode power consumption (Operating mode) QUIET |
760 W (AC 100–120 V), 730 W (AC 200–240 V) |
| Operation noise*1 |
42 dB (NORMAL/ECO), 38 dB (QUIET) |
| Dimensions (W x H x D) |
PT-REQ15 : 498 x 212 x 648 mm (19 19/32˝ x 8 11/32˝ x 25 1/2˝) (With feet at shortest position) PT-REQ15L : 498 x 212 x 538 mm (19 19/32˝ x 8 11/32˝ x 21 3/16˝ ) (With feet at shortest position) |
| Operating Environment |
Operating temperature: 0–45 °C (32–113 °F)*9, operating humidity: 10–80 % (no condensation) |
| Applicable Software |
Logo Transfer Software*10, Multi Monitoring & Control Software, Projector Network Setup Software, Real-Time Tracking Projection-Mapping System, Geometry Manager Pro, Smart Projector Control for iOS/Android™ |
| Control function via LAN |
Crestron Connected™ V2, Crestron XiO Cloud™, Art-Net DMX, AMX® DD, and PJLink™ (Class 2) |
| Note |
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is the average of all products when shipped. *2 When [OPERATING MODE] is set to [NORMAL]. *3 Average light output value of all shipped products measured at center of screen in [NORMAL] Mode. *4 Around this time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast Contents, Dynamic Contrast [3], temperature 35 °C (95 °F), elevation 700 m (2,297 ft) with 0.15 mg/m3 of airborne particulate matter. Estimated time until light output declines to 50 % varies depending on the environment. *5 Optional AJ-WM50 Series Wireless Module is not compatible with IPv6. *6 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. On-mode power consumption measured at 25 °C (77 °F) operating temperature at an altitude of 700 m (2,297 ft). *7 This value has included a maximum power consumption of 80 W when using a function board. *8 Average value. May differ depending on the actual unit. *9 When the optional AJ-WM50 Series wireless module is attached, the operating temperature range becomes 0–40 °C (32–104 °F). The operating environment temperature should be between 0 °C (32 °F) and 40 °C (104 °F) if the projector is used at an altitude between 1,400 m (4,593 ft) and 4,200 m (13,780 ft). *10 Excluding the REQ15. Software replaced with equivalent functions in the Web Control UI. |
| Weight*8 |
PT-REQ15 : Approx. 28.7 kg (63.27 lbs) (with supplied lens) PT-REQ15L : Approx. 27.0 kg (59.52 lbs) (without lens) |
| 1,140 W (11.5–4.7 A) (1,150 VA) (Power consumption is 1,090 W at AC 200–240 V) |
