Technical specifications

• Electrical
• Input 1 x
• Voltage 100 V loudspeaker line
• Detection threshold 5 to 50 V @ 20 kHz
• Output 2 x
• Indicator Green LED
• Contact Normally closed fail safe Bipolar MOS switch 250 Vp
•  Detection threshold* 5 to 50 V @ 20 kHz (contact and LED)
• * LED threshold and switch threshold may be slightly different.
• Mechanical
• Dimensions (H x W x D) 17 x 60 x 40 mm
• Mounting WLS II
• Weight Approx. 40 g
• Environmental
• Operating temperature -10 ºC to +55 ºC (14 ºF to +131 ºF)
• Storage and transport temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF)
• Relative humidity <95%
