| Display Technology |
DLP™ Technology by Texas Instruments |
| Resolution |
WUXGA 1920 x 1200 |
| Brightness1 (Bright Mode) |
5500 centre lumens (5300 ANSI) |
| Contrast |
300,000:1 (w/ dynamic black) |
| Typical lamp life2 Bright |
30000 hours to 50% brightness / Full brightness “Normal” (100% power) mode, temperature 25’C (hrs) |
| Throw Ratio 3 |
1.2:1 – 2.13:1 |
| Zoom Type |
1.8x manual |
| Lens Shift |
+20% vertical, ±10% horizontal, manual |
| I/O Connectors |
HDBaseT™, 3x HDMI, VGA In, Audio In, Mic In, VGA Out, Audio Out, RJ45, RS232C, Wired Remote, 12V Trigger, USB Power, Service Port, 3D Sync |
| Speaker |
10W x 2 |
| Keystone Correction |
±30° vertical, ±30° horizontal |
| Weight (kg) |
11 |
| Dimensions (W x D x H) (mm) |
403mm x 387mm x 148mm |
| Aspect Ratio |
16:10 native, 16:9 and 4:3 compatible |
| Offset |
100% – 120% |
| Projection Screen Size |
28″ to 302″ (71cm – 767cm), 16:10 |
| Projection Distance |
1.3m – 7.8m |
| Projection Lens |
1.8x manual zoom, manual focus |
| Uniformity |
85% |
| Maximum Resolution |
Native WUXGA (1920 x 1200) |
| Computer Compatibility |
WUXGA, HD, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible |
| Video Compatibility |
PAL (625/576i/p), SECAM, NTSC (525/480i/p), HDTV (720p, 1080i/1080p) |
| 3D Support |
Full 3D |
| 3D Compatibility |
Side-by-side, frame pack, over-under
|
| Horizontal Scan Rate |
15kHz to 100kHz |
| Vertical Scan Rate |
25Hz to 85Hz |
| Displayable Colours |
16.7 million |
| Noise Level (Eco mode) |
28dB (Eco mode) / 33dB (Normal mode) |
| Power Supply |
100 – 240V AC, 50 – 60Hz |
| Power Consumption |
480W bright mode, 320W eco mode, <0.5W standby (LAN off) |
| Lamp Type |
Laser-phosphor |
| Operating Conditions |
90% max humidity, 3000m max altitude |
| Operating Temperature |
5°C – 40°C
|
| Heat Dissipation |
1638 BTU/hr |
| Security |
4-digit PIN code, Kensington lock port, security bar |
| On Screen Display |
18 languages: English, German, French, Italian, Spanish, Portuguese, Polish, Dutch, Russian, Finnish, Swedish, Greek, Norwegian / Danish, Hungarian, Czech |
| Remote Control |
Infra-red remote control, wired connection |
| Standard Accessories |
VGA cable, AC power cord, Infra-red remote control, 2 x batteries, user manual CD, quick start card, WEEE card, warranty card |
| Optional Wireless |
Yes |
| 360’ Operation |
Yes |
| Portrait Mode |
Yes |
| Warranty |
3 Years |
| Conformances |
CE, TUV-GS, CB |
| RoHS |
RoHS and WEEE |
| DICOM Simulation Mode |
YES |
| Projection method |
360° operation, Portrait mode supported |
| Features |
PureShift lens shift, Crestron RoomView®, PJ-Link®, 360° operation, portrait projection |
