ตู้ลำโพง ยี่ห้อ EV,Electro-Voice รุ่น ZX5-60B

• DVX3150 15″ LF transducer with forced air cooling
• ND2 2″ voice coil, 1″ exit neodymium compression driver
• 90° x 50° coverage pattern
• 600W continuous (2400W) powerhandling
• High sensitivity, 132 dB maximum SPL
• Adjustable monitor angle (45° or 55°)
• 3 anchor plates for single stud fittings and
• 10 integral suspension points
• Available in black or white
• Passive/bi-amp selectable

Specifications

• Recommended High-Pass Frequency: 36 Hz
• Sensitivity 1W/1m: 98 dB
• Max. SPL / 1m (calc): 132 dB
• Coverage (nominal -6dB) H°: 60°
• Coverage (nominal -6dB) V°: 60°
• System Power Handling (continuous/program/peak): 600/1200/2400 watts
• Low Frequency Power Handling (continuous/program/peak): 500/1000/2000 watts
• High Frequency Power Handling (continuous/program/peak): 40/80/160 watts
• LF Transducer: DVX3150
• HF Transducer: ND2
• Crossover Frequency: 1500 Hz
• Nominal Impedance (Passive): 8 Ohms
• LF Nominal Impedance: 8 Ohms
• HF Nominal Impedance: 8 Ohms
• Minimum Impedance: 6.5 Ohms
• Color: Black
• Flying: Yes
• Input Connections: Parallel Neutrik NL4
• Outdoor: Yes
• Chassis Size: 15″
• Internal Crossover: Selectable
• Speaker Type: Fullrange, Mid-High, Two-Way, Wedges
• Weight Net: 22.5 kg ( 49.6 lb.)
• Dimensions (HxWxD): 692 x 446 x 411 mm (27.24″ x 17.56″ x 16.18″)
