| Native Resolution |
WXGA (1280 x 800) |
| Brightness |
3300 ANSI Lumens |
| Contrast Ratio |
10,000:1 |
| Max. Supported Resolution |
WUXGA (1920 x 1200) @60Hz |
| Native Aspect Ratio |
16:10 |
| Lamp Life and Type |
5,000 / 10,000 Hours (Normal / Eco. Mode), 230W/200W |
| Display Type |
Single chip DLP® Technology by Texas Instruments |
| Chip Size |
0.65” DMD |
| Throw Ratio |
0.35: 1 |
| Image Size (Diagonal) |
80″- 100″ |
| Projection Distance |
283 – 446 mm |
| Projection Lens |
F = 2.5, f = 5.1 mm |
| Zoom Ratio |
Fixed 1x |
| Lens Shift Range |
Limited Lens Shift Vertical ±1.7% |
| Offset |
120% |
| Interactivity |
Interactive pens & Optional Finger Touch |
| Keystone Correction |
Vertical: +/- 40° |
| Speakers |
10W x 2 |
| Video Compatibility |
SDTV (480i, 576i) / EDTV (480p, 576p) / HDTV (720p, 1080i, 1080p), NTSC (M, 3.58/4.43 MHz), PAL (B,D,G,H,I,M,N) SECAM (B,D,G,K,K1,L) |
| I/O Connection Ports |
VGA-In (15pin D-Sub) (x2), HDMI (x2), S-Video, Composite Video, Audio-In (RCA) , Audio-In (Mini-Jack), VGA-Out (15pin D-Sub), Audio-Out (Mini-Jack), RJ45, RS-232, USB A (Power Only), USB miniB (Interactivity), USB B (Service), Microphone (Mini-Jack), Interactive Function (Interactive pens & Optional Finger Touch) |
| Dimensions (W x D x H) |
287.7 x 374.5 x 122.6 mm (not including height of mirror ) |
| Weight |
5 kg |
| Noise Level |
33dB / 29dB (Normal / Eco. Mode) |
| Power |
Supply: AC 100-240V, 50/60Hz Consumption: 250W (Eco. Mode), 290W (Normal Mode), <0.5W (Standby) |
| 3D Ready(DLP link, PC+Video) |
Yes |
| Universal Wall Mount (T/R 0.35) |
%WM-3 |
| Standard Accessories |
VGA Cable, User Manual (CD), Quick Start Guide, Warranty Card (by region), Remote Controller (with battery), IR interactive Pen / nbr, AC Power Cord |
| Optional Accessories |
Spare Lamp P/N: 5811118004-SVV, 3D Glasses P/N: 3534257700, Universal Wall Mount (T/R 0.35), Remote Control P/N: 5041841300, Interactive Pen P/N: 5811118885-SVV |
| Warranty |
Education Warranty: 5 years projector / 3 years on lamp or 2.000 hours whichever comes first |
| UPC Code |
813097 021861 |
