Features:

• 15” high efficiency woofer
• 1.5” annular polymer diaphragm compression driver
• Enclosure constructed of premium plywood and finished in black DuraFlexTM coating
• 70° × 60° (H × V) coverage pattern for even and smooth response on and off axis
• Heavy-duty 16-gauge protective screen backed steel grille
• 12 rigging points for suspension installation

Specifications

• Frequency Range (-10 dB) : 40 Hz – 20 kHz
• Frequency Response (±3 dB) : 60 Hz – 20 kHz
• Coverage Pattern : 70° × 60° (H × V)
• Crossover Mode : Passive
• Crossover Frequency :1.9 kHz
• Power Rating : 900 W/1800 W/3600 W (Continuous/Program/Peak)
• Sensitivity (1w@1m) : 100 dB
• Nominal Impedance : 4 Ohms
• Maximum SPL : 130 dB (136 dB peak)
• LF Driver : 2 × 15” (381.00 mm) woofer
• HF Driver : 1 × JBL 2408H-1 tweeter
• Enclosure : Trapezoidal, 15/18 mm, plywood
• Suspension / Mounting : 12 points (3@top, 3@bottom, 2@each side, 2@rear), M10 thread hardware
• Transport : 2 × die-cast handles with backing cup
• Finish : Black DuraFlexTM finish
• Grille : Powder coated, black, 16-gauge perforated steel with acoustically transparent black screen backing
• Input Connectors : 2 × Neutrik® Speakon® NL-4
• Dimensions (H × W × D) : 1244 mm × 535 mm × 459 mm (49.0 in × 21.1 in × 18.1 in)
• Net Weight : 44.86 Kg (98.90 lbs)
