Features:

• 18” JBL 2044G woofer for extended low frequency output
• Large vent port for reduced distortion
• Enclosure constructed of premium plywood and finished in black DuraFlex™ coating
• Heavy-duty 16-gauge protective screen backed steel grille
• Top mounted socket for use with satellite speakers
• Low profile and compact design

Specifications

• Frequency Range (-10 dB) : 40 Hz – 200 Hz
• Frequency Response (±3 dB) : 45 Hz – 200 Hz
• Input Connection Modes : Internally configurable, +1/-1 or +2/-2
• Recommended Crossover : 80 Hz, 24 – 48 dB/octave
• Power Rating (Continuous/Program/Peak) : 500 W/1000 W/2000 W, 2 hrs  ,  400 W/800 W/1600 W, 100 hrs
• Maximum SPL : 127 dB continuous (133 dB peak)
• Sensitivity (1w@1m) : 94 dB SPL; 100 dB SPL
• LF Driver : 1 × 18” (457 mm) JBL 2044G woofer
• Nominal Impedance : 4 Ohms
• Mounting : Top mounted 35 mm socket for optional SS3-BK pole
• Enclosure : Rectangular, 18 mm, plywood
• Finish : Black DuraFlexTM finish
• Grille : Powder coated, black, 16-gauge perforated steel with acoustically transparent black screen backing
• Input Connectors : 2 × Neutrik® Speakon® NL-4
• Dimensions (H × W × D) : 548 mm × 533 mm × 700 mm (21.6 in × 21.0 in × 27.6 in)
• Net Weigh : 30.96 Kg (68.26 lbs)
• Optional Accessories : SS3-BK: Satellite speaker pole
