Features:

• 12” high efficiency woofer
• 5” annular polymer diaphragm compression driver
• Compact and low profile design for minimal obstruction of audience sight lines
• Enclosure constructed of premium plywood and finished in black DuraFlex™ coating
• 70° × 60° (H × V) coverage pattern for even and smooth response on and off axis
• Heavy-duty 16-gauge protective screen backed steel grille
• Dual-angle socket for pole mounting
• 13 rigging points for suspension installation

Specifications

• Frequency Range (-10 dB) : 50 Hz – 20 kHz
• Frequency Response (±3 dB) : 85 Hz – 20 kHz
• Coverage Pattern : 70° × 60° (H × V)
• Crossover Mode : Passive
• Crossover Frequency : 2.2 kHz
• Power Rating : 400 W/800 W/1600 W (Continuous/Program/Peak)
• Sensitivity (1w@1m) : 97 dB
• Nominal Impedance : 8 Ohms
• Maximum SPL : 123 dB (129 dB peak)
• LF Driver : 1 × 12” (304.8 mm) woofer
• HF Driver : 1 × JBL 2408H-2 tweeter
• Enclosure : Symmetrical stage monitor, 15/18 mm, plywood
• Suspension / Mounting : 13 points (3@top, 3@bottom, 2@each side, 3@rear), M10 thread hardware; Dual-angle 35 mm pole socket
• Transport : 1 × Integrated handle (input cup)
• Finish : Black DuraFlexTM finish
• Grille : Powder coated, black, 16-gauge perforated steel with acoustically transparent black screen backing
• Input Connectors : 2 × Neutrik® Speakon® NL-4 (1@each end)
• Dimensions (H × W × D) : 636 mm × 381 mm × 344 mm(25.0 in × 15.0 in × 13.5 in)
• Net Weight : 18 Kg (39.7 lbs)
• Optional Accessories : SS2-BK: Tripod speaker stand SS3-BK: Satellite speaker pole
