Features:

• Flat response curve for accurate reproduction of sound sources
• Low noise and high-output clipping level
• Low distortion over a wide range of load impedances
• Cardioid polar pattern effectively isolates source signal
• Low RF susceptibility
• Selectable low-frequency response: flat, 6 or 18dB/oct roll-off
• 0dB/10dB lockable attenuator switch
• Phantom powering (DIN 45 596 voltages of 12 to 48 Vdc)
• Rugged steel construction for durability
• Field-useable over wide range of temperature and humidity conditions

Specifications

• Transducer   :   (Electret Bias) Condenser
• Polar Pattern   :  Cardioid
• Frequency Response   :   20 Hz – 20 kHz
• Dynamic Range (Typical)   :   120 dB
• Signal-to-Noise Ratio   :  78 dB, (@ 94 dB SPL, IEC 651)
• Maximum Input Sound Level   :  136 dB, (@ 250 Hz 0.5% THD) /  146 dB, (with Pad)
• Power Requirements   :   Phantom 11 – 52v DC
• Output Impedance   :  150 Ohms (85 Ohms Actual)
• Output Connectors   :   XLR-3M Type
• Pad   :   -10 dB Attenuation
• Low Frequency Roll-Off   :   -6 dB/Octave @ 100 Hz   ,  -18 dB/Octave @ 80 Hz
• Applications   :  Sound Reinforcement, Broadcast and Studio Recording.
• Dimensions   :  212 x 23.5 mm LxDiameter
• Weight :  8 oz. (230 g)
