Technical specifications

Electrical

• Power consumption : 3.9 W (network)

External power supply

• Voltage : 24 to 56 VDC, 48 VDC nominal
• Current : 2.5 A maximum (5 A peak <2 s)

Mechanical

• Dimensions (H x W x D)
•  Without bracket : 27 x 243 x 80 mm (1.1 x 9.6 x 3.1 in)
•  With bracket : 34 x 243 x 84 mm (1.3 x 9.6 x 3.3 in)
• Weight:  0.7 kg (1.5 lb)
• Mounting : Bracket (two screws)
• Color : Charcoal

Environmental

• Operating temperature : -5 ºC to +55 ºC (+23 ºF to +131 ºF)
• Storage temperature : -20 ºC to +70 ºC (-4 ºF to +158 ºF)
• Relative humidity : 15% to 90%
• Air pressure : 600 to 1100 hPa
