Electrical*

Phantom power supply

• Voltage range 12 to 48 V
• Current consumption <8 mA
• Performance*
• Sensitivity 0.7 mV @ 85 dB SPL (2 mV/Pa)
• Maximum input sound level 110 dB SPL
• Distortion <0.6% (maximum input)
• Equivalent input noise level 28 dBA SPL (S/N 66 dBA ref. 1 Pa)
• Frequency response 100 Hz to 16 kHz
• Output Impedance < 200 ohm
• * Technical performance data acc. to IEC 60268-4

Mechanical

• Dimensions (D x L) 30 x 500 mm (19.69 x 1.18 in)
• Weight Approx. 300 g (10.5 oz)
• Color Dark gray
• Cable length 2 m (78 in)
• Connector 5‑pin DIN 180° (lockable)

Environmental

• Operating temperature -10 °C to +55 °C (+14 °F to +131 °F)
• Storage and transport
• temperature
• -40 °C to +70 °C (-40 °F to +158 °F)
• Relative humidity <95%
